Anenji 4.2KW 24V Hybrid Solar Inverter On grid Off grid Inverter with WIFI

About this product

• Product Manual： ANJ-4.2KW-W-LV MODEL ANJ-4.2KW-LV-W Capacity 4.2KVA/4.2KW Parallel Capability NO Split phase operation NO Built-in WIFI NO INPUT NominalVoltage 110/120VAC Acceptable Voltage Range 95-140VAC(ForpersonalComputer);70-140VAC(ForHomeAppliances) Frequency 50/60 Hz(Autosensing) OUTPUT Nominal Voltage 110/120VAC±5% Surge Power 8400VA Frequency 50/60Hz Waveform Pure Sine wave TransferTime 10ms(ForpersonalComputer);20ms(ForHomeAppliances) Peak Efficiency(PV to INV) 97% Peak Efficiency(Battery to INV) 93% Overload Protection 5s@>=140%load;10s@110%~140%load Crest Factor 3:1 Admissible Power Factor 0.6~1(inductive or capacitive) BATTERY Battery Voltage 24VDC Floating Charge Voltage 27VDC OverCharge Protection 32VDC Charging Method CC/CV Solar Charger & AC Charger Max.PV Array Power 6200W Solar Charger Type MPPT Max.PV Array Open Circuit Voltage 500VDC PV Array MPPT Voltage Range 60VDC~450VDC Max.Solar Input Current 27A Max.Solar Charge Current 120A Max.AC Charge Current 60A Max.Charge Current 120A PHYSICAL Dimensions,DxWxH（mm) 368x312.4x120.5 Package Dimensions,DxWxH（mm) 478x408x195mm NetWeight(Kg) 7.4 Grossweight(Kgs) 8.5 CommunicationInterface RS485/RS232/Dry-contact ENVIRONMENT Operating Temperature Range -10°Cto50°C Storage Temperature 15°C~50°C Humidity 5%to95%RelativeHumidity（Non-condensing) Ingress Protection IP21
