Anenji 5KW 48V Hybrid Solar Inverter On grid Off grid Inverter with WIFI 100A MPPT Dual Outputs

About this product

• EU and CHINA warehouses have stock available;Please note: *The EU warehouse can only ship to European regions.* Click to download ANENJI 5KW 48V Solar Inverter Manual You might also need a battery? Click here: ANENJI 48V 100Ah LiFePO4 battery PHASE 1-PhaseIn/1-PhaseOut Maximum PV input Power 5000W Maximum Main Output Power 5000VA/5000W Maximum Second Output Power 5000VA/5000W Maximum Total Output Power 5000VA/5000W Parallel Capability NO Lithium Batterya ctivation YES（By PV or Utility) Lithium Battery communication YES(RS485) AC INPUT Nominal Voltage 230VAC Acceptable Voltage Range 170-280VAC(ForpersonalComputer);90-280VAC(ForHomeAppliances) Frequency 50/60 Hz（Auto sensing) AC OUTPUT Nominal Voltage 220/230VAC+5% Surge Power 10000VA Frequency 50/60Hz Waveform Pure Sine wave Dual Outputs Yes Transfer Time 10ms(ForpersonalComputer);20ms(ForHome Appliances) Peak Efficiency(PV to INV) 96% Overload Protection 5s@>=140%load;10s@110%~140%load Admissible Power Factor 0.6~1（inductiveorcapacitive) BATTERY Battery Voltage 48VDC Floating Charge Voltage 54VDC OverCharge Protection 63VDC Charging Method CC/CV SOLARCHARGER & AC CHARGER Solar Charger TYPE MPPT Max. PV Array Power 5000W Max. PV Array Open Circuit Voltage 500VDC PV Array MPPT Voltage Range 60VDC~500VDC Max. Solar input Current 1/27A Max. Solar Charge Current 100A Max. AC Charge Current 60A Max. Charge Current 100A PHYSICAL Dimensions.DxWxH(mm) 312.4x350x114.5 Package Dimensions,DxWxH(mm) 475x390x180 NetWeight(Kgs) 8.5 Communication Interface RS485(RJ45) LCD ColorfulScreen+RGBLight ENVIRONMENT Operating Temperature Range -10°C to 50°c Storagetemperature -15°°C~50°℃ Humidity 5%to95%RelativeHumidity（Non-condensing)
